Samsung ARTSHZGWKYPM 1ton/1.5ton/2ton Heat & Cool DC Inverter AC

Samsung Wall Mounted Inverter AC AR4500 delivers rapid cooling with the Digital Inverter 8-Pole technology. Benefit from 2-Step Cooling and Triple Protector Plus for enhanced durability. The Auto Clean feature and Auto Change Over make it efficient. Perfect for those seeking quick, reliable cooling.

Features of Samsung Wall-Mounted Inverter AC

Specification	1 Ton 1200BTU	1.5 Ton 1800BTU	2 Ton 2400BTU
Mode	HEAT PUMP
Power Supply Φ,#,V,Hz	1,2,220-240,50
Cooling Capacity
Min/Rated/Max BTU/H	2,250/11,260/14,300	5,500/18,000/22,000	4780/22000/27000
Heating Capacity
Min/Rated/Max BTU/H	1,600/13,000/14,300	4,000/20,450/21,500	4100/22000/30400
Power Input (Nominal)
Cooling W	240/1025/1300	320/1630/2050	340/2000/2700
Heating W	210/1115/1350	270/1750/2000	280/1890/3750
Current Input (Nominal)
Cooling A	1.4/5/6	2/7.5/9.4	2.2/9.2/12
Heating A	1.2/5.2/6.2	1.7/7.5/9.4	1.8/9/17.2
Energy Efficiency
EER (Nominal Cooling)	3.22	3.24	3.22
COP (Nominal Heating)	3.42	3.42	3.4
Liquid Pipe
Type	Flare connection
Φ, mm	6.35
Gas Pipe
Type	Flare connection
Φ, mm	9.5	12.7	15.88
Piping Connection
Heat Insulation	Both liquid and gas pipes
Installation Max. Length	15	30	30
Installation Max. Height	7	15	15
Wiring Connections
Power Source Wire mm²	1.5	2.5	2.5
Communication Wire mm²	0.75
Refrigerant
Type	R410A
Factory Charging kg	1	1.1	1.4
Indoor Unit
Type	F&T
Heat Exchanger
Materials Fin	Al
Tube	Cu
Fin Treatment	Green Hydrophile
Fan
Type	BLDC(Cross Flow)
Motor (Output) Wxn	27×1
Air Flow Rate
Cooling (H/M/L)	10.5/9.5/8.5	16.5/15.1/13	1800/1440/1080
Drain Pipe Φ, mm	16.3,550
Sound Pressure (High/Silent)	41 / 21	43 / 25	44 / 28
Weight
Net kg	9	11.5	11.5
Shipping kg	10.5	13.2	13.2
Dimensions
Net (WxHxD) mm	820 x 299 x215	1055 x 299 x 215	1055 x 299 x 215
Shipping (WxHxD) mm	880 x 290 x 375	1115 x 290 x 375	1115 x 290 x 375
Outdoor Unit
Compressor
Type	BLDC Rotary	BLDC Rotary	BLDC Rotary
Output kW	2.8	4.57	4.57
Fan
Type	Propeller
Discharge direction	Front
Air Flow Rate (Cooling) CMM	40	45	50
Fan Motor Output Wxn	30×1	40×1	125×1
Sound Pressure Level (Cooling)	49	51	54
Weight
Net kg	27.1	32.3	42.7
Shipping kg	30	37.3	48
Dimensions
Net (WxHxD) mm	720 x 548 x 265	790 x 548 x 285	880 x 638 x 310
Shipping (WxHxD) mm	844 x 622 x 353	913 x 622 x 371	1023 x 724 x 413
